Description
General part information
4301.7204
Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange
Technical Specifications
Parameters and characteristics for this part
| Specification | 4301.7204 |
|---|---|
| Accomodates a Fuse | Yes (Fuse Not Included) |
| Approval Agency | CCC, cULus, ENEC |
| Connector Style | IEC 320-C14 |
| Connector Type | Male Blades - Module, Receptacle |
| Current Rating - Appliance Inlet | 2 A |
| Current Rating - Filter | 2 A |
| Filter Application | Medical, Commercial |
| Filter Subtype | EMI, RFI |
| Filter Type | Filtered |
| Fuse Holder, Drawer | Drawer Sold Separate |
| Ingress Protection | IP40 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Panel Mount, Flange |
| Number of Positions | 3 |
| Panel Cutout Length | 30.3 mm |
| Panel Cutout Shape | Rectangular |
| Panel Cutout Width | 34.3 mm |
| Termination | Quick Connect |
| Termination Probe Tip OD | 0.25 in |
| Voltage Rating - Appliance Inlet | 250 VAC |
