1788657
ActivePhoenix Contact
CONN WIRE TO BOARD M 9 POS 3.5MM SOLDER RA SIDE ENTRY THRU-HOLE TAPE
1788657
ActivePhoenix Contact
CONN WIRE TO BOARD M 9 POS 3.5MM SOLDER RA SIDE ENTRY THRU-HOLE TAPE
Description
General part information
1788657
9 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1788657 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.102 in |
| Current - UL | 8 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Liquid Crystal Polymer, LCP |
| Insulation Height | 0.272 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 9 |
| Pitch | 0.138 in |
| Positions Per Level | 9 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - UL | 300 V |
