1522D-62.500K33DTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 62.5MHZ 3.3V LVDS SM
1522D-62.500K33DTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 62.5MHZ 3.3V LVDS SM
Description
General part information
1522D-62.500K33DTSTK
62.5 MHz XO (Standard) LVDS Oscillator 3.3V Enable/Disable 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | 1522D-62.500K33DTSTK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 15 mA |
| Frequency | 62.5 MHz |
| Frequency Stability | 15 ppm, 25 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.043 in, 0.039 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | LVDS |
| Package / Case | No Lead, 6-SMD, 4-SMD |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Type | XO (Standard) |
| Voltage - Supply | 3.3 V |
