BQ024D0334J
ObsoleteKYOCERA AVX
CAP FILM 0.33UF 5% 63VDC RADIAL
BQ024D0334J
ObsoleteKYOCERA AVX
CAP FILM 0.33UF 5% 63VDC RADIAL
Description
General part information
BQ024D0334J
0.33 µF Film Capacitor 40V 63V Polyester, Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | BQ024D0334J |
|---|---|
| Applications | General Purpose |
| Capacitance | 0.33 µF |
| Dielectric Material | Polyester, Metallized |
| Height - Seated (Max) | 0.315 in |
| Lead Spacing | 0.2 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.295 in |
| Size / Dimension Width | 0.126 in |
| Termination | PC Pins |
| Tolerance | 5 % |
| Voltage Rating - AC | 40 V |
| Voltage Rating - DC | 63 V |
