135LC3600KL505HM6
ActiveCornell Dubilier Knowles
CAP FILM 1.32UF 10% 600VAC SMD
135LC3600KL505HM6
ActiveCornell Dubilier Knowles
CAP FILM 1.32UF 10% 600VAC SMD
Description
General part information
135LC3600KL505HM6
1.32 µF Film Capacitor 600V Polypropylene (PP) Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | 135LC3600KL505HM6 |
|---|---|
| Applications | High Pulse, DV/DT, Conduction Cooled |
| Capacitance | 1.32 µF |
| Dielectric Material | Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 0.3 mOhm |
| Height - Seated (Max) | 1.339 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Size / Dimension Length | 1.969 in |
| Size / Dimension Width | 1.969 in |
| Termination | Solder Pads |
| Tolerance | 10 % |
| Voltage Rating - AC | 600 VAC |
