Specification	AVR650UM

AC Outlet Types	Surge Only, UPS
AC Outlets (Count)	8 count
AC Outlets (Surge Only)	4 count
AC Outlets (UPS)	4 count
Applications	General Purpose, Industrial Control
Approval Agency	NOM, UL, CSA, FCC
Cord Length	5.9 ft
Form	Desktop
Height	3.504 in
Input Connector	NEMA 5-15P
Output Connector	NEMA 5-15R
Output Connector Quantity (NEMA 5-15R)	8
Power - Rated (VA)	650 VA
Power - Rated (W)	325 W
Size / Dimension Length	5.984 in
Size / Dimension Width	11.299 in
Type	Line Interactive (Input Regulation)
Voltage - Input	120 VAC
Voltage - Output	110 V, 120 V, 115 V
