5444628
ActivePhoenix Contact
TERM BLOCK HDR 19POS 3.81MM
5444628
ActivePhoenix Contact
TERM BLOCK HDR 19POS 3.81MM
Description
General part information
5444628
19 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5444628 |
|---|---|
| Color | Green |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.134 in |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Features | Mating Flange |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.291 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 19 |
| Pitch | 0.15 in |
| Positions Per Level | 19 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
