776309-1

Active

TE Connectivity AMP Connectors

CONN RCPT HSG 2POS 6.00MM

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN RCPT HSG 2POS 6.00MM

Technical Specifications

Parameters and characteristics for this part

Specification	776309-1

Color	Blue
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Male Pin
Fastening Type	Locking Ramp
Insulation Material	Nylon, Polyamide (PA), Glass Filled
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	2
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch [x]	0.236 in
Pitch [x]	6 mm
Row Spacing	6.3 mm
Row Spacing	0.248 in

CONN RCPT HSG 2POS 6.00MM

Part	Row Spacing	Row Spacing	Number of Rows	Number of Positions	Insulation Material	Connector Type	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Termination	Note	Mounting Type	Color	Pitch [x]	Pitch [x]	Contact Type
TE Connectivity AMP Connectors 776309-1	6.3 mm	0.248 in	2	2	Glass Filled, Nylon, Polyamide (PA)	Receptacle	Locking Ramp	-40 °C	105 ░C	Crimp	Contacts Not Included	Free Hanging (In-Line)	Blue	0.236 in	6 mm	Male Pin

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Rectangular Connectors - Housings Receptacle Blue 0.236" (6.00mm)
