SGM7MDS4T0000
ActiveMcGill Microwave Systems
SGM7MDS4T0000
SGM7MDS4T0000
ActiveMcGill Microwave Systems
SGM7MDS4T0000
Description
General part information
SGM7MDS4T0000
SGM7MDS4T0000
Technical Specifications
Parameters and characteristics for this part
| Specification | SGM7MDS4T0000 |
|---|---|
| Color | Gray |
| Connector Style | Power |
| Connector Type | Male Pins, Plug |
| Connector Usage | Backplane |
| Contact Finish | Gold |
| Contact Finish Thickness | 15 µin |
| Features | Jackscrews |
| Mounting Type | Through Hole |
| Number of Columns | 4 |
| Number of Positions | 7 |
| Number of Positions Loaded | 2 |
| Number of Rows | 2 |
| Pitch | 0.094 in |
| Termination | Solder |
