Specification	1559247

Backshell Material	Brass
Cable Opening (Max)	0.669 in
Cable Opening (Min)	0.315 in
Color	Black, Silver
Connector Type	Male Pins, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Zinc
Current Rating	15 A
Fastening Type	Threaded
Features	Coupling Nut, Backshell
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Insert Material	Polyvinyl Chloride, PVC
Mounting Type	Free Hanging (In-Line)
Number of Positions	6
Orientation	A
Plating	Nickel
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert (Maximum)	6 in, 6
Shell Size - Insert (Minimum)	0.875 in, 0.875
Shielding	Unshielded
Termination	Screw
Voltage Rating	600 V
