PLED150W-333-C0450-D

Active

Thomas Research Products

LED DRVR CC AC/DC 111-333V 450MA

Search across all available documentation for this part.

Active

Thomas Research Products

LED DRVR CC AC/DC 111-333V 450MA

Technical Specifications

Parameters and characteristics for this part

LED DRVR CC AC/DC 111-333V 450MA

Part	Current - Output (Max) [Max]	Number of Outputs	Power (Watts)	Features	Voltage - Input (Min) [Min]	Ratings	Termination Style	Topology	Voltage - Input (Max) [Max]	Efficiency	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Mounting Type	Dimming	Type	Voltage - Output [Max]	Voltage - Output [Min]	Weight	Weight
Thomas Research Products PLED150W-333-C0450-D	450 mA	1	150 W	OCP, OVP, SCP	100 VAC	IP66, NEMA 6	Wire Leads	AC DC Converter	277 VAC	92 %	CE, cURus	2.33 in	7.6 in	59.2 mm	1.47 in	37.3 mm	193 mm	Chassis Mount	Analog	Constant Current	333 V	111 V	725.7 g	1.6 lbs

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	500	$ 134.03

General part information

450mA 111 ~ 333V Constant Current LED Driver AC DC Converter Topology 1 Output
