LD150W-48-C3150-RD

Obsolete

EPtronics, Inc.

LED DRIVER AC/DC CC 16-48V 3.15A

Search across all available documentation for this part.

Obsolete

EPtronics, Inc.

LED DRIVER AC/DC CC 16-48V 3.15A

Technical Specifications

Parameters and characteristics for this part

LED DRIVER AC/DC CC 16-48V 3.15A

Part	Power (Watts)	Approval Agency	Voltage - Input (Max) [Max]	Dimming	Voltage - Output [Min]	Voltage - Output [Max]	Ratings	Type	Operating Temperature [Min]	Operating Temperature [Max]	Topology	Current - Output (Max) [Max]	Mounting Type	Termination Style	Voltage - Input (Min) [Min]	Features	Number of Outputs	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Isolation	Efficiency
EPtronics, Inc. LD150W-48-C3150-RD	150 W	CE, cUL, cURus, FCC	305 VAC	Analog, PWM	16 V	48 V	IP66	Constant Current	-30 ░C	60 °C	AC DC Converter	3.15 A	Chassis Mount	Wire Leads	90 VAC	OCP, OVP, SCP	1	2.33 in	7.2 in	1.47 in	37.3 mm	59.2 mm	182.9 mm	3750 V	89 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

3.15A 16 ~ 48V Constant Current LED Driver AC DC Converter Topology 1 Output
