Description
General part information
R413W422050P0K
2.2 µF Film Capacitor 300V 1200V (1.2kV) Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | R413W422050P0K |
|---|---|
| Applications | EMI, Automotive, RFI Suppression |
| Capacitance | 2.2 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 1.579 in |
| Lead Spacing | 1.476 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Ratings | AEC-Q200, Y2, X1 |
| Size / Dimension Length | 1.634 in |
| Size / Dimension Width | 0.787 in |
| Termination | PC Pins |
| Tolerance | 10 % |
| Voltage Rating - AC | 300 V |
| Voltage Rating - DC | 1200 V |
