453-00138
ActiveEzurio LLC
RF TXRX MOD BT I CHIP + U.FL SMD
453-00138
ActiveEzurio LLC
RF TXRX MOD BT I CHIP + U.FL SMD
Description
General part information
453-00138
Bluetooth, WiFi 802.11a/b/g/-c, Bluetooth v5.1 Transceiver Module 2.4GHz, 5GHz Integrated, Chip + U.FL Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 453-00138 |
|---|---|
| Antenna Type | Integrated, Chip + U.FL |
| Data Rate | 780 Mbps |
| Frequency | 2.4 GHz, 5 GHz |
| Frequency | 2.4GHz, 5GHz |
| Memory Size | 2 Gbit |
| Memory Size (Flash) | 500 MB |
| Memory Type | Flash, RAM |
| Modulation | 256-QAM, QPSK, BPSK, 64-QAM, CCK, 16-QAM |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| Package / Case | Module |
| Power - Output | 18 dBm |
| Protocol | 802.11a, Bluetooth v5.1, 802.11-c, 802.11b, 802.11g |
| RF Family/Standard | WiFi, Bluetooth |
| Sensitivity | -95 dBm |
| Serial Interfaces | USB, GPIO, UART, SPI, I2C |
| Voltage - Supply (Maximum) | 3.3 V |
| Voltage - Supply (Minimum) | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
