Y16087R20000B0L
ActiveVPG Foil Resistors
VCS232Z 7R20000 0.1%
Y16087R20000B0L
ActiveVPG Foil Resistors
VCS232Z 7R20000 0.1%
Description
General part information
Y16087R20000B0L
7.2 Ohms ±0.1% 2W Through Hole Resistor 4-SIP Current Sense, Non-Inductive Metal Foil
Technical Specifications
Parameters and characteristics for this part
| Specification | Y16087R20000B0L |
|---|---|
| Composition | Metal Foil |
| Features | Current Sense, Non-Inductive |
| Height - Seated (Max) | 0.512 in |
| Number of Terminations | 4 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 4-SIP |
| Package Name | 4-SIP |
| Power (Watts) | 2 w |
| Resistance | 7.2 Ohms |
| Size / Dimension Length | 1.24 in |
| Size / Dimension Width | 0.177 in |
| Temperature Coefficient | 0.2 ppm/°C |
| Tolerance | 0.1 % |
