17S681KLF
ActiveGowanda Electronics
MOLDED SHIELDED RF COILS AXIAL
17S681KLF
ActiveGowanda Electronics
MOLDED SHIELDED RF COILS AXIAL
Description
General part information
17S681KLF
6.8 µH Shielded Molded Inductor 280 mA 1.02Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | 17S681KLF |
|---|---|
| Current Rating | 0.28 A |
| DC Resistance (DCR) (Max) | 1.02 Ohm |
| Frequency - Self Resonant | 55 MHz |
| Inductance | 6.8 µH |
| Inductance Frequency - Test | 7.9 MHz |
| Material - Core | Iron Powder |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Q | 50 |
| Shielding | Shielded |
| Size / Dimension Diameter | 0.162 in |
| Size / Dimension Length | 0.41 in |
| Tolerance | 10 % |
| Type | Molded |
