RSF-1962.500-63800-1109-TR
ActiveRaltron Electronics
FILTER SAW 1.9625GHZ 5SMD
RSF-1962.500-63800-1109-TR
ActiveRaltron Electronics
FILTER SAW 1.9625GHZ 5SMD
Description
General part information
RSF-1962.500-63800-1109-TR
1.9625GHz Frequency Cell Phone RF SAW Filter (Surface Acoustic Wave) 2.7dB 63.8MHz Bandwidth 5-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | RSF-1962.500-63800-1109-TR |
|---|---|
| Applications | Cell Phone |
| Bandwidth | 63.8 MHz |
| Frequency - Center | 1.9625 GHz |
| Height (Max) | 0.026 in |
| Insertion Loss | 2.7 dB |
| Mounting Type | Surface Mount |
| Package / Case | 5-SMD, No Lead |
| Size / Dimension Length | 0.043 in |
| Size / Dimension Width | 0.035 in |
