5-104912-2
ActiveTE Connectivity AMP Connectors
08/16 MTE HDR SRST LTCH .100CL
5-104912-2
ActiveTE Connectivity AMP Connectors
08/16 MTE HDR SRST LTCH .100CL
Description
General part information
5-104912-2
PCB Mount Header, Vertical, Wire-to-Board, 8 Position, 2.54 mm [.1 in] Centerline, Fully Shrouded, Tin-Lead, Through Hole - Solder, Signal, Black
Technical Specifications
Parameters and characteristics for this part
| Specification | 5-104912-2 |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 30 µin |
| Contact Length - Mating | 0.23 in |
| Contact Length - Post | 0.13 in |
| Contact Material | Brass |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating | 3 A |
| Fastening Type | Latch Holder |
| Features | Keying Slot |
| Insulation Color | Black |
| Insulation Height | 0.535 in |
| Insulation Material | Thermoplastic |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 16 |
| Number of Positions Loaded | 8 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -65 °C |
| Overall Contact Length | 0.545 in |
| Pitch - Mating | 0.1 in |
| Shrouding | Shrouded - 4 Wall |
| Style | Board, Board or Cable |
| Termination | Solder |
