0ALDE9200-BE
ActiveBel Fuse Inc.
FUSE 20A 800V RADIAL 10.3 X 39.4MM CERAMIC
0ALDE9200-BE
ActiveBel Fuse Inc.
FUSE 20A 800V RADIAL 10.3 X 39.4MM CERAMIC
Description
General part information
0ALDE9200-BE
20A 800 VDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 0ALDE9200-BE |
|---|---|
| Applications | Electrical, Industrial |
| Breaking Capacity | 50 kA |
| Current Rating | 20 A |
| DC Cold Resistance | 0.0052 Ohms |
| Fuse Type | Cartridge |
| Melting I²t | 1000 |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial Bend Cylinder |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 1.583 in |
| Voltage Rating - DC | 800 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
