2485925-1
ActiveTE Connectivity AMP Connectors
RF ADAPTERS - IN SERIES SMA JACK TO TNC JACK ADAPT STRAIGHT FLANGE MNT 25.40MM 11 GHZ STAINLESS STL 50 OHM
2485925-1
ActiveTE Connectivity AMP Connectors
RF ADAPTERS - IN SERIES SMA JACK TO TNC JACK ADAPT STRAIGHT FLANGE MNT 25.40MM 11 GHZ STAINLESS STL 50 OHM
Description
General part information
2485925-1
In-Series Adapter, Straight, SMA Side A, Jack Side A, N Type Side B, Jack Side B, 2 Position
Technical Specifications
Parameters and characteristics for this part
| Specification | 2485925-1 |
|---|---|
| Adapter Series | SMA to N |
| Adapter Type | Jack to Jack |
| Center Contact Plating | Gold |
| Center Gender | Female |
| Conversion Type | Between Series |
| Convert From (Adapter End) | SMA Jack, Female Socket |
| Convert To (Adapter End) Gender | Female Socket |
| Convert To (Adapter End) Type | N Jack |
| Fastening Type | Threaded |
| Frequency - Max | 11 GHz |
| Impedance | 50 Ohm |
| Mounting Feature | Flange |
| Mounting Type | Panel Mount |
| Style | Straight |
