Specification	1129940

Adjustment Type	Teaching Method
Cable Length	78.74 in
Connection Method	Cable
Ingress Protection	IP67, IP69, IP66
Light Source	Red
Light Source Wavelength (Red)	655 nm
Operating Temperature (Max)	55 °C
Operating Temperature (Min)	-20 °C
Output Configuration	PNP - Dark-ON, Push-Pull, Light-ON, NPN
Response Time	200 µs
Sensing Distance Maximum	16.535 "
Sensing Distance Minimum	0.591 "
Sensing Method	Proximity
Voltage - Supply (Maximum)	30 VDC
Voltage - Supply (Minimum)	10 VDC
