BD-08AFFM-SR7A04
ActiveMcGill Microwave Systems
SENSOR CABLES / ACTUATOR CABLES CERES, STANDARD SIZE, PLASTIC, 5A, 08 PINS, FEMALE CONNECTOR, FEMALE CONTACT, RIGHT ANGLE, SCREW THREAD, OVERMOLDED, LENGTH 4000MM, IP67
BD-08AFFM-SR7A04
ActiveMcGill Microwave Systems
SENSOR CABLES / ACTUATOR CABLES CERES, STANDARD SIZE, PLASTIC, 5A, 08 PINS, FEMALE CONNECTOR, FEMALE CONTACT, RIGHT ANGLE, SCREW THREAD, OVERMOLDED, LENGTH 4000MM, IP67
Description
General part information
BD-08AFFM-SR7A04
Cable Assembly 13.12' (4.00m)
Technical Specifications
Parameters and characteristics for this part
| Specification | BD-08AFFM-SR7A04 |
|---|---|
| 1st Connector Gender | Female Sockets |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 8 positions |
| 1st Connector Number of Positions Loaded | All |
| 1st Connector Orientation | Keyed |
| 1st Connector Shell Size - Insert | B |
| 1st Connector Type | Right Angle, Receptacle |
| 2nd Connector Type | Wire Leads |
| Assembly Configuration | Standard |
| Cable Material | Polyvinyl Chloride (PVC) |
| Cable Type | Round |
| Color | Black |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Length | 13.12 ft |
| Shielding | Shielded |
| Usage | Industrial Environments |
