B84144A0080R000
ActiveEPCOS - TDK Electronics
LINE FILTER 440V/250VAC 80A CHAS
B84144A0080R000
ActiveEPCOS - TDK Electronics
LINE FILTER 440V/250VAC 80A CHAS
Description
General part information
B84144A0080R000
Three Phase (Wye) EMC/EMI Line Filter 80 A 440V, 250V 50 ~ 60Hz Single Stage Terminal Block, Threaded Post (M10)
Technical Specifications
Parameters and characteristics for this part
| Specification | B84144A0080R000 |
|---|---|
| Applications | General Purpose |
| Approval Agency | UL |
| Configuration | Single Stage |
| Current | 80 A |
| Filter Subtype | Wye |
| Filter Type | Three Phase |
| Frequency - Operating (Max) | 60 Hz |
| Frequency - Operating (Min) | 50 Hz |
| Mounting Type | Chassis Mount |
| Termination Style | Terminal Block, Threaded Post (M10) |
| Voltage - Rated AC | 440V, 250V |
| Voltage - Rated AC (Phase to Ground/Neutral) | 250 V |
| Voltage - Rated AC (Phase to Phase) | 440 V |
