Description
General part information
06-66-102
15 A Snap Action Switch, Single Pole - Single Throw Configuration (Pole-Throw), Bar-Type Knob, 24 VDC, 250 VAC, 200 g [7 oz] Operating Force, Vertical
Technical Specifications
Parameters and characteristics for this part
| Specification | 06-66-102 |
|---|---|
| Actuator Type | Mushroom Button |
| Circuit | SPST-NO |
| Current Rating | 15 A |
| Differential Travel (Linear) | 0.012 in |
| Ingress Protection Description | High Temp Water Jets, Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP69K |
| Mounting Type | Panel Mount |
| Operating Force | 2041 gf |
| Pretravel (Length) | 0.08 in |
| Switch Function | Off-On |
| Termination Style | Cable Leads |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | 24 V |
