Specification	2012010042

Connector Type	Header
Contact Finish - Mating	Tin
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	39.4 µin
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating	0 A
Current Rating	Varies by Wire Gauge
Fastening Type	Latch Holder
Features	Solder Retention
Insulation Color	Red
Insulation Height	0.354 in
Insulation Material	Nylon, Glass Filled, Polyamide (PA)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	4
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch - Mating	0.079 in
Shrouding	Shrouded - 4 Wall
Style	Cable/Wire, Board
Termination	Solder
Voltage Rating	250 V

201201 Series

Part	Operating Temperature (Min)	Operating Temperature (Max)	Style	Fastening Type	Number of Rows	Features	Mounting Type	Contact Finish - Mating	Material Flammability Rating	Insulation Material	Insulation Height	Voltage Rating	Number of Positions Loaded	Current Rating	Pitch - Mating	Number of Positions	Contact Finish Thickness - Mating	Insulation Color	Contact Material	Contact Type	Termination	Contact Shape	Contact Finish - Post	Connector Type	Shrouding	Applications	Contact Finish Thickness - Post
Molex 2012010152	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	15	39.4 µin	Red	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010160	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	16	39.4 µin	Natural	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall
Molex 2012010024	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	2	39.4 µin	Blue	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall
Molex 2012010041	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	4	39.4 µin	Black	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010044	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	4	39.4 µin	Blue	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010060	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	6	39.4 µin	Natural	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010163	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	16	39.4 µin	Yellow	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010040	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	4	39.4 µin	Natural	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010150	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	15	39.4 µin	Natural	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
Molex 2012010020	-40 °C	105 °C	Board Cable/Wire	Latch Holder	1	Solder Retention	Surface Mount	Tin	UL94 V-0	Glass Filled Nylon Polyamide (PA)	0.354 in	250 V	All	Varies by Wire Gauge	0.079 in	2	39.4 µin	Natural	Brass	Male Pin	Solder	Square	Tin	Header	Shrouded - 4 Wall	General Purpose	39.4 µin
