Specification	1300970174

Color	Silver
Includes	Grommet, Compression Nut, Strain Relief
Material	Aluminum
Outside Cable Diameter (Max)	1.125 in
Outside Cable Diameter (Min)	1 in
Thread Size (Diameter)	1 in
Thread Type	NPT
Type	Cable Grip

130097 Series

Cable Glands, Strain Reliefs & Cord Grips DELUXE CORD GRIP STRAIN RELIEF

...

Part	Includes	Outside Cable Diameter (Min)	Material	Thread Size (Diameter)	Thread Type	Color	Angle	Type	Outside Cable Diameter (Max)	Thread Length
Molex 1300970218	Compression Nut Grommet Strain Relief	0.625 in	Aluminum	1 in	NPT	Silver	90 °	Cable Grip - Cable Grip - 90°	0.75 in
Molex 1300970264	Locknut Strain Relief	0.52 in	Aluminum	0.75 in	NPT	Silver		Cable Grip	0.73 in	0.67 in
Molex 1300970250	Compression Nut Grommet Strain Relief	0.187 in	Aluminum	0.375 in	NPT	Silver		Cable Grip	0.25 in
Molex 1300970190	Compression Nut Grommet Strain Relief	2.312 in	Aluminum	2 in	NPT	Silver		Cable Grip	2.437 in
Molex 1300970160	Compression Nut Grommet Strain Relief	0.187 in	Aluminum	0.5 in	NPT	Silver		Cable Grip	0.25 in
Molex 1300970238	Compression Nut Grommet Strain Relief	1.25 in	Aluminum	1.5 in	NPT	Silver		Cable Grip	1.375 in
Molex 1300970191	Compression Nut Grommet Strain Relief	0.25 in	Aluminum	0.75 in	NPT	Silver		Cable Grip	0.375 in
Molex 1300970178	Compression Nut Grommet Strain Relief	1.13 in	Aluminum	1.25 in	NPT	Silver		Cable Grip	1.37 in
Molex 1300970327	Compression Nut Grommet Strain Relief	0.562 in	Stainless Steel	0.5 in	NPT	Gray		Cable Grip	0.625 in	0.5 in
Molex 1300970329	Compression Nut Grommet Strain Relief	0.44 in	Stainless Steel	0.75 in	NPT	Silver		Cable Grip	0.56 in	0.562 in
