4303-355-000-26

Active

Excelitas Technologies

LED RED 1010 SMD

Search across all available documentation for this part.

Active

Excelitas Technologies

LED RED 1010 SMD

Technical Specifications

Parameters and characteristics commom to parts in this series

LED RED 1010 SMD

Part	Wavelength - Peak	Lens Style	Millicandela Rating	Height (Max) [Max] [z]	Current - Test	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Supplier Device Package	Color	Mounting Type	Voltage - Forward (Vf) (Typ)
Excelitas Technologies 4303-355-000-22	650 nm	Irregular	3 mcd	1 mm	0.5 mA	1010 (2525 Metric)	2.5 mm	2.5 mm	1010	Red	Surface Mount
Excelitas Technologies 4303-355-000-20	575 nm	Irregular	6.5 mcd	1 mm	5 mA	1010 (2525 Metric)	2.5 mm	2.5 mm	1010	Green	Surface Mount	2.3 V
Excelitas Technologies 4303-355-000-26	650 nm	Irregular		1 mm	0.5 mA	1010 (2525 Metric)	2.5 mm	2.5 mm	1010	Red	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Strip	50	$ 14.53

General part information

Red LED Indication - Discrete 1010 (2525 Metric)

Technical documentation and resources
