Specification	AGL600V5-FG256

Mounting Type	Surface Mount
Number of Gates	600000
Number of I/O	177
Number of Logic Elements/Cells	13824
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	0 °C
Package / Case	256-LBGA
Package Length	17 mm
Package Name	256-FPBGA
Package Width	17 mm
Total RAM Bits	110592 bits
Voltage - Supply (Maximum)	1.575 V
Voltage - Supply (Minimum)	1.425 V

AGL600V5 Series

Ultra Low Density FPGAs

Part	Total RAM Bits	Number of Logic Elements/Cells	Package Length	Package Name	Package Width	Mounting Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Operating Temperature (Max)	Operating Temperature (Min)	Number of I/O	Number of Gates	Package / Case
Microchip Technology AGL600V2-FG144I	110592 bits	13824	13 mm	144-FPBGA	13 mm	Surface Mount	1.575 V	1.14 V	85 °C	-40 °C	97	600000	144-LBGA
Microchip Technology AGL600V5-FG256I	110592 bits	13824	17 mm	256-FPBGA	17 mm	Surface Mount	1.575 V	1.425 V	85 °C	-40 °C	177	600000	256-LBGA
Microchip Technology AGL600V5-FG144	110592 bits	13824	13 mm	144-FPBGA	13 mm	Surface Mount	1.575 V	1.425 V	70 °C	0 °C	97	600000	144-LBGA
Microchip Technology AGL600V5-FGG144I	110592 bits	13824	13 mm	144-FPBGA	13 mm	Surface Mount	1.575 V	1.425 V	85 °C	-40 °C	97	600000	144-LBGA
Microchip Technology AGL600V5-CSG281I	110592 bits	13824	10 mm	281-CSP	10 mm	Surface Mount	1.575 V	1.425 V	85 °C	-40 °C	215	600000	281-TFBGA CSBGA
Microchip Technology AGL600V2-FG256	110592 bits	13824	17 mm	256-FPBGA	17 mm	Surface Mount	1.575 V	1.14 V	70 °C	0 °C	177	600000	256-LBGA
Microchip Technology AGL600V2-FGG144I	110592 bits	13824	13 mm	144-FPBGA	13 mm	Surface Mount	1.575 V	1.14 V	85 °C	-40 °C	97	600000	144-LBGA
Microchip Technology AGL600V5-FGG256I	110592 bits	13824	17 mm	256-FPBGA	17 mm	Surface Mount	1.575 V	1.425 V	85 °C	-40 °C	177	600000	256-LBGA
Microchip Technology AGL600V2-FGG256	110592 bits	13824	17 mm	256-FPBGA	17 mm	Surface Mount	1.575 V	1.14 V	70 °C	0 °C	177	600000	256-LBGA
Microchip Technology AGL600V5-FGG256	110592 bits	13824	17 mm	256-FPBGA	17 mm	Surface Mount	1.575 V	1.425 V	70 °C	0 °C	177	600000	256-LBGA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

AGL600V5-FG256 | Datasheet
