RN222-0.8-02
ObsoleteTE Connectivity AMP Connectors
CMC 39MH 800MA 2LN TH
RN222-0.8-02
ObsoleteTE Connectivity AMP Connectors
CMC 39MH 800MA 2LN TH
Description
General part information
RN222-0.8-02
39 mH @ 1 kHz 2 Line Common Mode Choke Through Hole 800mA (Typ) DCR 1Ohm (Typ)
Technical Specifications
Parameters and characteristics for this part
| Specification | RN222-0.8-02 |
|---|---|
| Approval Agency | UR, VDE |
| Current Rating (Max) | 800 mA |
| Current Rating (Typ) | 800 mA |
| DC Resistance (DCR) (Max) | 1 Ohm |
| DC Resistance (DCR) (Typ) | 1 Ohm |
| Filter Type | Power Line |
| Height (Max) | 1.165 in |
| Inductance | 39 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 4 PC Pin, Vertical |
| Package Leads | 4 Leads |
| Package Name | Vertical |
| Size / Dimension Length | 1.22 in |
| Size / Dimension Width | 0.709 in |
| Voltage Rating - AC | 250 V |
