CEB-1213-L100
ActiveSame Sky (Formerly CUI Devices)
BUZZER ELEMENT STD 4KHZ 12MM
CEB-1213-L100
ActiveSame Sky (Formerly CUI Devices)
BUZZER ELEMENT STD 4KHZ 12MM
Description
General part information
CEB-1213-L100
4 kHz Standard Buzzer Element 30V p-p 0.472" Dia (12.00mm) 1.5 kOhms
Technical Specifications
Parameters and characteristics for this part
| Specification | CEB-1213-L100 |
|---|---|
| Capacitance | 12000 pF |
| Frequency | 4 kHz |
| Impedance | 1.5 kOhms |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -20 °C |
| Size / Dimension Diameter | 0.472 in |
| Termination | Wire Leads |
| Type | Standard |
| Voltage - Input (Max) | 30 V p-p |
