FAN BLOWER 97X33MM 24VDC WIRE
CBM-979433S-225-467-20
ActiveSame Sky (Formerly CUI Devices)
FAN BLOWER 97X33MM 24VDC WIRE
Description
General part information
CBM-979433S-225-467-20
Fan Blower 24VDC Rectangular/Rounded - 97mm L x 94.8mm H Sleeve 15.1 CFM (0.423mł/min) 3 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CBM-979433S-225-467-20 |
|---|---|
| Air Flow | 15.1 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Sleeve |
| Current Rating | 0.18 A |
| Fan Type | Blower |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 39.5 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 4.8 W |
| RPM | 2500 RPM |
| Size / Dimension Height | 94.8 mm |
| Size / Dimension Length | 97 mm |
| Size / Dimension Shape | Rectangular/Rounded |
| Static Pressure | 0.28 in H2O |
| Termination | 3 Wire Leads |
| Termination Leads Count | 3 |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 5.5 VDC |
| Voltage Range (Min) | 4.5 VDC |
| Width | 33 mm |
