1689718
ActivePhoenix Contact
DSUB GENDER CHANGER DB15F DB15F
1689718
ActivePhoenix Contact
DSUB GENDER CHANGER DB15F DB15F
Description
General part information
1689718
Adapter Connector D-Sub, 15 Pin Female To D-Sub, 15 Pin Female Panel Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 1689718 |
|---|---|
| Connector Style | Gender Changer |
| Contact Finish | Gold |
| Convert From (Adapter End) Pin Count | 15 pins |
| Convert From (Adapter End) Pin Gender | Female |
| Convert From (Adapter End) Type | D-Sub |
| Convert To (Adapter End) | D-Sub, Pin Female |
| Convert To (Adapter End) Pin Count | 15 pins |
| Current Rating | 5 A |
| Housing Color | Gray |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Panel Mount |
| Number of Rows | 2 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Shielding | Shielded |
| Voltage Rating | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
