TB0010-500-06GR
ActiveSame Sky (Formerly CUI Devices)
6 POLES, SCREW TYPE, HORIZONTAL,
TB0010-500-06GR
ActiveSame Sky (Formerly CUI Devices)
6 POLES, SCREW TYPE, HORIZONTAL,
Description
General part information
TB0010-500-06GR
6 Position Wire to Board Terminal Block Horizontal with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | TB0010-500-06GR |
|---|---|
| Color | Green |
| Contact Material | Copper Alloy |
| Current | 16 A |
| Features | Interlocking (Side) |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.197 in |
| Plating | Tin Plated |
| Positions Per Level | 6 |
| Screw Thread | M3 |
| Torque - Screw | 0.5 Nm |
| Voltage | 250 V |
| Wire Gauge (AWG) (Max) | 22 AWG |
| Wire Gauge (AWG) (Min) | 14 AWG |
| Wire Termination | Screw |
