LRC20-4R7M-RC
ActiveAllied Components International
4.7UH +/-20% LO-RES CHIP
LRC20-4R7M-RC
ActiveAllied Components International
4.7UH +/-20% LO-RES CHIP
Description
General part information
LRC20-4R7M-RC
4.7 µH Unshielded Wirewound Inductor 450 mA 260mOhm Max 1210 (3225 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | LRC20-4R7M-RC |
|---|---|
| Current Rating | 0.45 A |
| DC Resistance (DCR) (Max) | 260 mOhm |
| Frequency - Self Resonant | 43 MHz |
| Height - Seated (Max) | 0.087 in |
| Inductance | 4.7 µH |
| Inductance Frequency - Test | 1 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | 1210 (3225 Metric) |
| Package Name | 1210 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.098 in |
| Tolerance | 20 % |
| Type | Wirewound |
