PIN HEADER, PCB HEADER, BOARD-TO-BOARD, 3.5 MM, 1 ROWS, 2 CONTACTS, THROUGH HOLE

Find alt
14120214001000

14120214001000

Active
HARTING

PIN HEADER, PCB HEADER, BOARD-TO-BOARD, 3.5 MM, 1 ROWS, 2 CONTACTS, THROUGH HOLE

Find alt

Description

General part information

14120214001000

2 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) Vertical Through Hole

Technical Specifications

Parameters and characteristics for this part

Specification14120214001000
ColorBlack
Contact MaterialCopper Alloy
Contact Mating FinishTin
Current - UL11 A
Header OrientationVertical
Housing MaterialPPA, PA, Polyphthalamide, Polyamide, Nylon
Insulation Height0.362 in
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Levels1
Number of Positions2
Operating Temperature (Max)110 °C
Operating Temperature (Min)-40 °C
Pitch0.138 in
Positions Per Level2
Termination StyleSolder
TypeShrouded (4 Side), Male Pins, Header
Voltage - UL300 V
