AJ15HV
ActiveKnowles Syfer
CAP TRIMMER 1-16PF 1000V SMD
AJ15HV
ActiveKnowles Syfer
CAP TRIMMER 1-16PF 1000V SMD
Description
General part information
AJ15HV
1 ~ 16pF Trimmer Capacitor 1000 V Side Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | AJ15HV |
|---|---|
| Adjustment Type | Side |
| Capacitance Range (Max) | 16 pF |
| Capacitance Range (Min) | 1 pF |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Features | General Purpose |
| Height - Seated (Max) | 12.7 mm |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -65 °C |
| Q | 2000 |
| Size / Dimension Diameter | 0.25 in |
| Voltage - Rated | 1000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
