VTX-214-005-109

VTX-214-005-107

Active
Vigortronix

AC/DC PCB MOUNT POWER SUPPLY, CLASS II, FIXED, 90 V, 265 V, 5 W, 7.5 V, 666 MA ROHS COMPLIANT: YES

Find alt
VTX-214-005-109

VTX-214-005-107

Active
Vigortronix

AC/DC PCB MOUNT POWER SUPPLY, CLASS II, FIXED, 90 V, 265 V, 5 W, 7.5 V, 666 MA ROHS COMPLIANT: YES

Find alt

Description

General part information

VTX-214-005-107

Enclosed AC DC Converters 1 Output 7V 666mA 90 ~ 264 VAC, 100 ~ 370 VDC Input

Technical Specifications

Parameters and characteristics for this part

SpecificationVTX-214-005-107
ApplicationsITE (Commercial), Household Appliances
Approval AgencyIEC, UL, EN
Current - Output (Max)666 mA
Efficiency70 %
Mounting TypeThrough Hole
Number of Outputs1
Operating Temperature (Max)70 °C
Operating Temperature (Min)-40 °C
Package / Case4-DIP Module
Power (Watts)5 W
Size / Dimension Height0.77 in
Size / Dimension Length1.26 in
Size / Dimension Width1.06 in
Standard Number62368-1, 61558-2, 61000
TypeEnclosed
Voltage - Input (AC) Maximum264 V
Voltage - Input (AC) Minimum90 V
Voltage - Input (DC) Maximum370 V
Voltage - Input (DC) Minimum100 V
Voltage - Output 17 V
Weight0.071 lb
