ST32TA502
ObsoleteVishay Dale
TRIMMER 5K OHM 0.125W J LEAD TOP
ST32TA502
ObsoleteVishay Dale
TRIMMER 5K OHM 0.125W J LEAD TOP
Description
General part information
ST32TA502
5 kOhms 0.125W, 1/8W J Lead Surface Mount Trimmer Potentiometer Cermet 1.0 Turn Top Adjustment
Technical Specifications
Parameters and characteristics for this part
| Specification | ST32TA502 |
|---|---|
| Adjustment Type | Top Adjustment |
| Mounting Type | Surface Mount |
| Number of Turns | 1 turns |
| Power (Watts) | 0.125 W |
| Power (Watts) Options | 1/8W |
| Resistance | 5 kOhm |
| Resistive Material | Cermet |
| Size / Dimension Length | 0.134 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 0.134 in |
| Temperature Coefficient | 100 ppm/°C |
| Termination Style | J Lead |
| Tolerance | 20 % |
