FOCM3ODMPMB24-20
ActivePasternack
IP68 -MPO/UPC MALE, TYPE B, TO I
FOCM3ODMPMB24-20
ActivePasternack
IP68 -MPO/UPC MALE, TYPE B, TO I
Description
General part information
FOCM3ODMPMB24-20
Cable Fiber Optic MPO/UPC To MPO/UPC 50/125 65.6' (20.0m)
Technical Specifications
Parameters and characteristics for this part
| Specification | FOCM3ODMPMB24-20 |
|---|---|
| 1st Connector | MPO/UPC |
| 2nd Connector | MPO/UPC |
| Cable Diameter | 0.2 " |
| Color - Cable | Black |
| Fiber Cladding Diameter | 125 µm |
| Fiber Core Diameter | 50 µm |
| Insertion Loss | 0.75 dB |
| Jacket (Insulation) Material | Low Smoke Zero Halogen (LSZH) |
| Length - Overall | 65.6 ft |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -40 °C |
| Return Loss | 25 dB |
| Type | Multimode, OM3 |
