18M681M
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXL
18M681M
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXL
Description
General part information
18M681M
6.8 µH Unshielded Molded Inductor 560 mA 375mOhm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | 18M681M |
|---|---|
| Current Rating | 0.56 A |
| DC Resistance (DCR) (Max) | 375 mOhm |
| Frequency - Self Resonant | 50 MHz |
| Inductance | 6.8 µH |
| Inductance Frequency - Test | 7.9 MHz |
| Material - Core | Iron Powder |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Q | 30 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.188 in |
| Size / Dimension Length | 0.438 in |
| Tolerance | 20 % |
| Type | Molded |
