DE6B3KJ101KB4BE01J
ActiveMurata Electronics
CAP CERAMIC SAFETY 100PF X1/Y2
DE6B3KJ101KB4BE01J
ActiveMurata Electronics
CAP CERAMIC SAFETY 100PF X1/Y2
Description
General part information
DE6B3KJ101KB4BE01J
100 pF ±10% 300VAC Ceramic Capacitor B Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | DE6B3KJ101KB4BE01J |
|---|---|
| Applications | Automotive, Safety |
| Capacitance | 100 pF |
| Height - Seated (Max) | 0.354 in |
| Lead Spacing | 0.394 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Disc, Radial |
| Ratings | AEC-Q200, Y2, X1 |
| Size / Dimension Diameter | 0.236 in |
| Temperature Coefficient | B |
| Tolerance | 10 % |
| Voltage - Rated | 300 VAC |
