615R150GAD10
ActiveVishay Dale
CAP CER 1000PF 15KV Y5U RADIAL
615R150GAD10
ActiveVishay Dale
CAP CER 1000PF 15KV Y5U RADIAL
Description
General part information
615R150GAD10
1000 pF -20%, +80% 15000V (15kV) Ceramic Capacitor Y5U (E) Radial, Disc
Technical Specifications
Parameters and characteristics for this part
| Specification | 615R150GAD10 |
|---|---|
| Applications | SMPS Filtering |
| Capacitance | 1000 pF |
| Features | High Voltage |
| Height - Seated (Max) | 0.921 in |
| Lead Spacing | 0.752 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Disc, Radial |
| Size / Dimension Diameter | 0.669 in |
| Temperature Coefficient | Y5U (E) |
| Tolerance (Negative) | 20 % |
| Tolerance (Positive) | 80 % |
| Voltage - Rated | 15000 V |
