Specification	MAL250057152E3

Applications	General Purpose
Capacitance	1500 µF
ESR (Equivalent Series Resistance)	79 mOhm
Height - Seated (Max)	4.362 in
Impedance	61 mOhms
Lead Spacing	0.874 in
Lifetime	3000 Hrs
Mounting Type	Chassis Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Screw Terminals, Radial
Polarization	Polar
Ripple Current	14.2 A
Size / Dimension Diameter	1.969 in
Tolerance	20 %
Voltage - Rated	450 V
