V250LA40A
ActiveON Semiconductor
RADIAL LEAD VARISTOR
V250LA40A
ActiveON Semiconductor
RADIAL LEAD VARISTOR
Description
General part information
V250LA40A
390 V 6.5 kA Varistor 1 Circuit Through Hole Disc 20mm
Technical Specifications
Parameters and characteristics for this part
| Specification | V250LA40A |
|---|---|
| Capacitance | 1 pF |
| Current - Surge | 6.5 kA |
| Energy | 130 J |
| Maximum AC Volts | 250 V |
| Maximum DC Voltage | 330 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -55 °C |
| Package Diameter | 20 mm |
| Package Name | Disc |
| Varistor Voltage (Max) | 429 V |
| Varistor Voltage (Min) | 351 V |
| Varistor Voltage (Typ) | 390 V |
