Description
General part information
PRCM12-4DP
The PRCM12-4DP is a DC type cylindrical connector Inductive Proximity Sensor with PNP Output. The PRCM series makes maintenance and wiring works easier than ever. Also, it realizes world-best class superior noise resistance characteristics with dedicated IC.
Technical Specifications
Parameters and characteristics for this part
| Specification | PRCM12-4DP |
|---|---|
| Indicator | LED |
| Ingress Protection | IP67 |
| Material - Body | Nickel-Plated Brass |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Output Type | PNP-NO, 3-Wire |
| Package / Case | Threaded - M12, Cylinder |
| Response Frequency | 500 Hz |
| Sensing Distance | 0.157 " |
| Sensor Type | Inductive |
| Shielding | Unshielded |
| Termination Style | Connector |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
