Specification	B41605A7398M002

Applications	Automotive
Capacitance	3900 µF
ESR (Equivalent Series Resistance)	26 mOhm
Height - Seated (Max)	1.654 in
Lead Spacing	0.394 in
Lifetime	5000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package Leads	3 Leads
Package Name	Radial, Can - Snap-In
Polarization	Polar
Ripple Current	6.5 A
Size / Dimension Diameter	0.866 in
Tolerance	20 %
Voltage - Rated	40 V
