TM5SDM12DT
ActiveSCHNEIDER ELECTRIC
I/O MODULE, 1 WIRE, 8 I/4 O DIGITAL, TRANSISTOR, 24 VDC, IP20, MODICON TM5 SERIES
TM5SDM12DT
ActiveSCHNEIDER ELECTRIC
I/O MODULE, 1 WIRE, 8 I/4 O DIGITAL, TRANSISTOR, 24 VDC, IP20, MODICON TM5 SERIES
Description
General part information
TM5SDM12DT
Input, Output (I/O) Module DIN Rail 24VDC
Technical Specifications
Parameters and characteristics for this part
| Specification | TM5SDM12DT |
|---|---|
| Approval Agency | GOST, C-Tick, UL, cULus, IEC, CSA |
| For Use With/Related Products | Modicon TM5 Series |
| Ingress Protection | IP20 |
| Input Types | Digital |
| Mounting Type | DIN Rail |
| Number of Inputs | 8 |
| Number of Outputs | 4 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -10 °C |
| Output Type | Digital |
| Termination Style | Screw Terminal |
| Type | Output (I/O) Module, Input |
| Voltage - Supply | 24 VDC |
