M9L33480
ActiveSURGE PROTECTOR, SURGE ARRESTER, 3 POLE, TYPE 1, 75 KA, 480 V, DIN RAIL
M9L33480
ActiveSURGE PROTECTOR, SURGE ARRESTER, 3 POLE, TYPE 1, 75 KA, 480 V, DIN RAIL
Description
General part information
M9L33480
M9L33480 is a multi9 PRD1 surge arrester. It can be installed in a variety of installations including service entrance, branch panels and control panel environments. It is connected to electrical distribution network. This surge arrester class type is type 1. The Imax maximum discharge current is 75kA. It can be associated with a 30A and C curve tripping circuit breaker. The Uc maximum continuous operating voltage is 175VAC in common mode (L/N). The IN nominal discharge current is 20kA ( L/PE). The Up maximum voltage protection level is 600V. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The degree of protection is NEMA 1. The operating temperature is -25°C to 60°C. This product complies with UL 1449 standard.
Technical Specifications
Parameters and characteristics for this part
| Specification | M9L33480 |
|---|---|
| Current - Discharge (Max) | 75 kA |
| Current - Discharge (Nom) | 20 kA |
| Form | Module, Base |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -25 °C |
| Type | Type 1 |
| Voltage - Continuous Operating (Max) (MCOV) | 640 V |
| Voltage - Protection Level (VP) (2416) | 2 kV |
