EC3AE33M
ActiveCincon Electronics Co. LTD
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC-DC CONVERTER, 3 WATT, 28VDC INPUT, 15VDC OUTPUT, DIP
EC3AE33M
ActiveCincon Electronics Co. LTD
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC-DC CONVERTER, 3 WATT, 28VDC INPUT, 15VDC OUTPUT, DIP
Description
General part information
EC3A Series
Isolated Module DC DC Converter 1 Output 15V 200mA 25.2V - 30.8V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | EC3AE33M |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 200 mA |
| Efficiency | 61 % |
| Features | SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -25 °C |
| Package Leads | 12 Leads |
| Package Name | 24-DIP Module |
| Power (Watts) | 3 W |
| Size / Dimension Height | 0.4 in |
| Size / Dimension Length | 1.25 in |
| Size / Dimension Width | 0.8 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 30.8 V |
| Voltage - Input (Min) | 25.2 V |
| Voltage - Isolation | 500 V |
| Voltage - Output 1 | 15 V |
