Description
General part information
112KD53
1.1 kV 70 kA Varistor 1 Circuit Through Hole Disc 53mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 112KD53 |
|---|---|
| Capacitance | 2700 pF |
| Current - Surge | 70000 A |
| Energy | 2050 J |
| Maximum AC Volts | 680 V |
| Maximum DC Voltage | 895 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Diameter | 53 mm |
| Package Name | Disc |
| Varistor Voltage (Max) | 1210 V |
| Varistor Voltage (Min) | 990 V |
| Varistor Voltage (Typ) | 1100 V |
